Description
- Ideal for large boardrooms and classrooms
- Automatic voice tracking
- Camera Lense Parameters
- Image Sensor: 1080P 1/2.8" CMOS senzo
- Effective Pixel: 2.2M
- Zoom: 10X optical zoo
- Shutter Speed: 1 to 1/10000
- Focal lens: 2.8mm Fixed / f=5.1mm-51.0mm, F=1.8(W)-2.5(T)
- Horizontal Field of View: 72
- Auto Focus
- Aperture mode: Auto
- Microphone Parameters
- Mic Array Quantty: 4
- Mic Array Form: Linear
- Sensitivity: -29dBFs
- Far-field Pick up Voice Distance: 10meter
- Horizontal Voice Pick up Angle: Horizontal 180°
- Interface Parameters
- Video Interface: USB2.0
- Video Compressed Format: MJPEG
- Control Interface: RS-232, USB2.0, UVC
- Control Agreement: VISCA/PELCO-D/PELCO-P
- Communicate Baud Rate: 2400/4800/9600/115200
- Power Interface: DC-038 power socket(DC12V)
- PTZ Parameter
- Pan Rotation: -170°~ +173°
- Tilt Rotation: -30°~ +90°
- Horizontal Rotate Speed: 0.1~100°/second
- Vertical Rotate Speed: 0.1~80°/ second
- Other Parameters
- Power Adapter: Input AC100V~AC240V Output DC12V/2A
- Decoder: Built in
- Input voltage: DV12V
- Power Consumption: 12W (MAX)
- Storage Temperature & Humidity: -10°C ~ +60°C / 20% ~ 95%
- Working temperature & Humidity: -10°C ~ +50°C / 20% ~ 80%
- Operating Environment: Indoor
- Baud Rate: 2400/4800/9600/115200
- Protocol: VISCA / PELCO-D / PELCO-P
- Address Setting: 1~255
- Size: 160.7*115.1*131.4mm
- Weight: 600g
Note: This product has a 2 year warrantee
